We are proud to be the 1st sunscreen fabric supplier in China to produce fiberglass screens for both interior and exterior applications. A Fiberglass shadecloth offers superior protection against heat and harmful rays from the sun, due to its fireproofing nature and strong resistance to heat.Fiberglass screen has the following long lasting characteristics.

1. Flame proof
3. Dimensional stability
4. Heat resistance
5. Durability
6. Easy maintenance
7. Energy saving
8. No curling or waving

Technical characteristics

Composition 30% fiberglass, 70% PVC
Weight 470g/m2±5% GB/T4669-2008
Thickness 0.54mm±5% FZ/T01003-1991
Tensile Strength Warp 2250N/5cm,Weft 1660N/5cm DIN53354:1981
Tearing Strength Warp 85N, Weft 76N DIN53363:2003
Elongation Warp 6%,Weft 3%
Openness Factor 5% FZ/T01009-2008
Color Fastness 8/7/4.5 GB/T8427-2008/ ISO 105 B02/ ATCC
Fire Resistance B2(Oxygen.Index≥27mm)/NFPA701/M2 GB 50222-95/ NFPA701/ NFP92-503
UV screen 95%
Environment HJ/T307-2006 OEKO-TEX STANDARD 100CLASS ZV GREEN GUARD ECOSPECIFIER CETEC
Pattern plain weaving
Making-up high frequency welding, ultrasonic welding,
Width 2.0M/2.5M
Length 27.4m/roll GB/T4669-2008

Colors

Application
Roller Blind Garden Shade Skylight blinds Panel Shades
    - used indoors        - used outdoors
Certificates
